G 1 1/2 - G 1 1/2 | |
---|---|
B1 | G 1 1/2 |
B2 | G 1 1/2 |
L | 132 mm |
ØD | 30 mm |
NV | 60 mm |
ØA | 65 mm |
Part No.: | 5001589 |
Type: | Inner x Outer |
Type of connection: | G-G |
Max work pressure: | 30 MPa |
Max peak pressure: | 45 MPa |
Seal kit: | 5001636 |
