Part No.: | 5212049 |
Type of rotator: | Grapple rotator |
Weight: | 54.2 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212170 |
Type of rotator: | Grapple rotator |
Weight: | 48.3 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212050 |
Type of rotator: | Grapple rotator |
Weight: | 55.4 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212349 |
Type of rotator: | Grapple rotator |
Weight: | 54.2 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5112189 |
Type of rotator: | Grapple rotator |
Weight: | 60.5 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212052 |
Type of rotator: | Grapple rotator |
Weight: | 55.7 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212275 |
Type of rotator: | Grapple rotator |
Weight: | 57.7 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212276 |
Type of rotator: | Grapple rotator |
Weight: | 58.2 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow:: | 25 l/min |
Part No.: | 5212280 |
Type of rotator: | Grapple rotator |
Weight: | 57 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212475 |
Type of rotator: | Grapple rotator |
Weight: | 57.7 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212277 |
Type of rotator: | Grapple rotator |
Weight: | 59.2 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
Part No.: | 5212282 |
Type of rotator: | Grapple rotator |
Weight: | 58.1 kg |
Rotation: | 360° |
Max axial load, static: | 100 kN |
Max axial load, dynamic: | 50 kN |
Torque at 25 Mpa: | 2200 Nm |
Rotation max oilflow: | 25 l/min |
